Skaitmeninis osciloskopas 2x100 MHz
Skaitmeninis osciloskopas 2x100 MHz
Kodas: 3B Scientific 1020911Kaina 93303 € su PVMPrekę turime sandėlyje. Užsakius ir apmokėjus šiandien iki 14 val., pristatytume kitą darbo dieną.
Šiuo metu prekės nėra sandėlyje. Numatomas pristatymo laikas nurodytas žemiau.
Pateikus užsakymą, susisieksime su Jumis ir informuosime apie tikslų numatomą užsakymo pristatymo laiką.
GamintojasPristatymo laikas3-6 savaitės-
Informacija apie prekę Prekės kodas 1020911 [U11835] Svoris 2.9 kg Ženklas PeakTech
Digital Oscilloscope 2x100 MHzLatest generation, dual-channel digital storage oscilloscope for many applications with the following features:
- High-resolution colour display and back-lighting
- Large internal data memory
- VGA output for connecting external monitor
- LAN connection for remote access via network
- USB port for real-time data transmission or for reading internal memory
- Autoset and autoscale functions for user-friendly operation
- 20 automatic measuring modes plus FFT function
- PASS/FAIL function
Channels: Two
Band width: 100 MHz
Sample rate: Dual CH 500 MS/s
Single CH 1 GS/s
Operating modes: CH1, CH2, XY
Input:
Input coupling: DC, AC, GND
Input impedance: 1 MΩ ±2% ll 10 pF ±5 pF
Input voltage: 0 – 400 V DC or ACpp
Vertical:
Deflection coefficient: 2 mV/div. – 10 V/div.
Precision: ± 3%
A/D converter: 8-bit resolution
Horizontal:
Time-base coefficient: 2 ns/div. – 100 s/div.
Sampling range: 0.5 S/s – 250 MS/s
Precision: 100 ppm
Measuring mode:
Automatic measurement: Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, overshoot, pre-shoot, rise time, fall time, +width, -width, +duty, -duty, delay A-B (rising), delay A-B (falling), freq, period, FFT
Maths functions: +, -, *, /, FFT
Trigger:
Trigger type: Edge, Video, Pulse, Slope
Trigger modes: Auto, Normal, Single
Trigger detection: Sample, peak detect, average
Interfaces:
Memory size: 10000 measurements
Interface: USB 2.0, VGA, LAN
Power supply: 100 – 240 V, 50/60 Hz
General data:
Display: TFT colour screen, 8 inches, 800 x 600 pixels, 65536 colours
Dimensions: 340x155x70 mm³ approx.
Weight: 1.8 kg approx.
