Oro takelis
Oro takelis
Kodas: 3B Scientific 1021090Kaina 139755 € su PVMPrekę turime sandėlyje. Užsakius ir apmokėjus šiandien iki 14 val., pristatytume kitą darbo dieną.
Šiuo metu prekės nėra sandėlyje. Numatomas pristatymo laikas nurodytas žemiau.
Pateikus užsakymą, susisieksime su Jumis ir informuosime apie tikslų numatomą užsakymo pristatymo laiką.
GamintojasPristatymo laikas3-6 savaitės-
Informacija apie prekę Prekės kodas 1021090 [U206101] Svoris 12 kg
Air TrackTrack with square profile and 2 gliders for investigating frictionless linear motion. Mounted on a robust U-shaped base resting on three feet that can be adjusted to ensure horizontal alignment. The air is blown in from the front and escapes through small air outlets arranged in 2 rows along the track. This allows for practically frictionless movement of the gliders on the triangular track with no tilting. With millimetre tape measure.
Material: Anodised aluminium
Total length: 2.00 m
Working length: 1.90 m
Maximum deviation from straight line over complete length: 0.02 mm
Track profile: Square, 63x63 mm2
Thickness of walls: 3 mm
Separation of air outlets holes: 20 mm
Base profile: U-shaped profile
Width of base: 40 mm
Height of base: 40 mm
Wall thickness of base: 4 mm
Contents:
1 Air track on U-shaped base profile resting on three feet
2 Gliders made of black anodised aluminium with 4-mm holes to accommodate velocity flags and other accessories, plus pins at the sides to hold additional weights, mass: 180 g, length: 125 mm
4 Additional 50 g weights
1 Set of slotted weights with holder, 2x 1 g, 1x 2 g, 1x 5 g, 1x 10 g, holder 2 g
2 Velocity flags with plug for interrupting light barriers, mass: 5 g, width: 25 mm
3 Forks with plugs and rubber bands for catapulting gliders and investigating elastic collisions, mass: 10 g
3 Plates with plugs for investigating elastic collisions, mass: 10 g
1 Needle with plug for investigating inelastic collisions, mass: 10 g
1 Small tube with plug and plastic filling for investigating inelastic collisions, mass: 10 g
1 Hook with plug for attaching a thread with accelerating weights on the end, mass: 10 g
1 Pulley for frictionless deflection of accelerated masses
1 Set of screws and tools for assembling air track
1 Manual
